CLUTCH TYPE |
SIZE |
FREE SPEED (rpm) |
AVERAGE AIR CONSUMPTION ( 25% )SCFM |
MAX TORQUE (n-m) |
MAX TORQUE (ft-lb) |
SOUND dBA (pressure) |
SOUND dBA (power) |
VIBRATION (m/s2) |
EXHAUST |
LENGTH (mm) |
LENGTH (inch) |
WEIGHT (kg) |
WEIGHT (lbs) |
AIR PRESSURE (psi) |
AIR PRESSURE (kg/cm2) |
AIR INLET |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| TWIN | 3/4" | 8,000 | 8.7 | 1,490 | 1,100 | 92.5 | 103.5 | 6.02 | HANDLE | 190 | 7.5 | 2.3 | 5.07 | 90 | 6.3 | 3/8" |
